VIRTUS CT1
CITY BIKE
COLOR
GREY-BLACK
MOTOR
OLI SPORT PLUS – 85NM
BATTERY
36V – 15AH – 540WH
MOTOR DATA
Motor 250 Watt
Maximun Torque 85 Nm
Motor Weight 3.500 Gr
Battery 540 Wh
Battery Weight 3.000 Gr
Battery Range Till 150 Km
AUTONOMY PERFORMANCE IN KMS OF THE TORQUE DRIVE SYSTEM
DISPLAY HIGH VISION
– 2“ screen size
– 31,8mm handlebar bracket
– Light sensor
– Remote control
– Walk mode on the remote control
– BT / ANT+ connectivity
GEOMETRY
| SIZE | RC | WB | BBD | ST | STACK | REACH | TT | HT | FL | FR | SA | HA |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| M | 460 | 1112 | 70 | 450 | 667 | 396 | 600 | 170 | 477 | 42 | 73° | 70° |
COMPONENTS
| TIRES | 29x2.0”kENDA KHAN k935 |
| WHEELS | ITALIA RIM PASSION DH 34 |
| FRAME | HYDROFORMED ALUMINIUM |
| FORK | SUNTOUR SR NVX SF15 NVX30 TRAVEL 63MM |
| STEM | ZOOM STEM EXT 75MM |
| HANDLEBAR | ZOOM ALLOY W600 BARBORE 31.8MM BLACK MATT |
| SADDLE | SELLE ITALIA MAX S5 SF L FEC |
| SEAT TUBE | ZOOM SHOCK ABSORBER SEAT POST SPS-521 EXTENTION 350 |
| CHAINWHEEL | CHAINWHEEL SET 38T |
| PEDALS | NON-SLIP PEDAL |
| BRAKES | HYDRAULIC shimano mt 200 o tektro hd-275 disco 160mm |
| GEAR | SHIMANO GEAR SHIFTER 7 SPEED |
| DERAILLEUR | SHIMANO TY300D |
| CASSETTE | SHIMANO FREEWHEEL 14-34T 7-SPEED |
| DISPLAY | MULTIFUNCTION COMPUTER OLI EDS COLOR DISPLAY |
| MOTOR | OLI EDS MOTOR TORQUE SYSTEM 250W SPORT(85NM) |
| MAX SPEED | 25 KM/H |
| BATTERY | LI-ION FRAME INTEGRATE 36V 15AH 540WH REMOVABLE |
| BATTERY WEIGHT | 3,0 KG |
| CHARGE TIME | 6-7 HOUR |
| MINIMUM CHARGE | 30-40 DAYS |
| AUTONOMY | SEE DATA SHEET |
| WEIGHT | 26 KG |
| REAR CARRIER LOAD CAPACITY | 15 KG |
| MAX CAPACITY | 100 KG |
| FRONT/REAR LIGHT | LED INTEGRATED POWER SUPPLY |
Technical characteristics and components may be subject to changes without prior notice.
