VIRTUS CT1

VIRTUS CT1


MOTOR

OLI EDS MOTOR TORQUE SYSTEM 250W SPORT – 85NM

BATTERY

36V – 15AH – 540WH

MOTOR DATA

Motor 250 Watt
Maximun Torque 85 Nm
Motor Weight 3.500 Gr
Battery 540 Wh
Battery Weight 3.000 Gr
Battery Range Till 165 Km

AUTONOMY PERFORMANCE IN KMS OF THE TORQUE DRIVE SYSTEM

* Data depend on the road condition and load. Test carried out on computerized test bench.

DISPLAY HIGH VISION
– 2“ screen size
– 31,8mm handlebar bracket
– Light sensor
– Remote control
– Walk mode on the remote control
– BT/ANT+ connectivity

GEOMETRY


SIZERCWBBBDSTSTACKREACHTTHTFLFRSAHA
M4601112704506673966001704774273°70°

COMPONENTS


TIRES29 X 2.0" R.ACER GOLDEN
WHEELSITALIA RIM PASSION DH 34
FRAMEHYDROFORMED ALUMINIUM
FORKSUNTOUR SR NVX SF15 NVX30 TRAVEL 63MM
STEMZOOM STEM EXT 75MM
HANDLEBARZOOM ALLOY W600 BARBORE 31.8MM BLACK MATTE
SADDLESELLE ITALIA MAX S5 SF L FEC
SEAT TUBEZOOM SHOCK ABSORBER SEAT POST SPS-521 EXTENTION 350
CHAINWHEELCHAINWHEEL SET 38T
PEDALSNON-SLIP PEDAL
BRAKESHYDRAULIC ZOOM BRAKE KIT HB- 875/CR01 ROTOR 160MM
GEARSHIMANO GEAR SHIFTER 7 SPEED
DERAILLEURSHIMANO TY300D
CASSETTESHIMANO FREEWHEEL 14-34T 7-SPEED
DISPLAYMULTIFUNCTION COMPUTER OLI EDS COLOR DISPLAY
MOTOROLI EDS MOTOR TORQUE SYSTEM 250W SPORT(85NM)
MAX SPEED25 KM/H
BATTERYLI-ION FRAME INTEGRATE 36V 15AH 540WH REMOVABLE
BATTERY WEIGHT3,0 KG
CHARGE TIME6-7 HOUR
MINIMUM CHARGE30-40 DAYS
AUTONOMYSEE DATA SHEET
WEIGHT26 KG
REAR CARRIER LOAD CAPACITY15 KG
MAX CAPACITY100 KG
FRONT/REAR LIGHTLED INTEGRATED POWER SUPPLY

Technical characteristics and components may be subject to changes without prior notice.
